NEWPPAP + AS9102 FAI FOR US TIER-2 / TIER-3 SUPPLIERS
Your PPAP is due Friday. Have it back in minutes.
PXL Kraft builds your PPAP package. Upload the drawing and your routing: every characteristic is ballooned in seconds, and a submission-ready Level 3 comes back in minutes, in your customer’s template. An engineer checks every characteristic before it leaves.
- FREE TRIAL ON YOUR NEXT PART
- FASTEST BALLOONING OUT THERE
- ENGINEER-REVIEWED
- YOUR CUSTOMER'S TEMPLATE
Level 3 package
- Ballooned drawing
- Process flow
- PFMEA (draft)
- Control plan
- Dimensional layout
- Cpk · your data
- PSW
Part no.
PK-7734-A
Elapsed
0:00
Checked
0 / 4
Checked by
PENDING
In
Drawing + routing
PDF · SCAN · DXF · PHOTO
PXL Kraft
balloon → plan → control → assemble
BALLOONED IN SECONDS · BACK IN MINUTES
Out
PPAP package
YOUR CUSTOMER’S FORMAT · ENGINEER-REVIEWED
- Ballooning
- Seconds
- PPAP package back
- Minutes
- Characteristics ballooned
- Every one
- Numbers invented
- Zero
One upload, five steps, back in minutes.
You spend about fifteen minutes uploading. Ballooning takes seconds and the full package takes minutes. A named engineer checks every characteristic before it's released.
- 1YOU · ABOUT 15 MIN
Upload the drawing and routing
Any age, any format, multi-sheet. A clean PDF or a forty-year-old scan, a DXF or a phone photo, plus the routing you already run.
- 2AI · SECONDS
Every characteristic ballooned, in seconds
Dimensions, tolerances, GD&T, threads, notes and title-block general tolerances. Inch or metric. Each one numbered and pinned to the print before you've closed the upload window.
- 3AI · MARKED DRAFT
Process flow and PFMEA from your routing
Your operations become the process flow diagram, and the PFMEA is drafted against them. Both are marked draft. You sign off.
- 4AI
Control plan and dimensional layout, keyed to the balloons
Every row carries its balloon number, in your customer's template. Your CMM results drop straight into the layout.
- 5AI + NAMED ENGINEER · MINUTES
PSW filled, binder assembled, engineer-reviewed
Checked against customer-specific requirements: Ford, GM, Stellantis, Kohler or generic AIAG. Then a named engineer checks every characteristic and releases it.
The fastest ballooning out there. Every characteristic, in seconds.
Ballooning a print by hand eats three to four hours of retyping tolerances. PXL Kraft reads the drawing and balloons every characteristic in seconds, then builds the rest of your PPAP from those numbers. Watch it on a sample part.
Characteristics
0 / 15
- 1Overall width120.0 ±0.3
- 2Mounting holes4× ⌀8.5 +0.2/0
- 3Center hole⌀44.0 ±0.1
- 4Hole spacing, vertical60.0 ±0.1
- 5Flatness, base⏥ 0.2
- 6Flange height40.0 ±0.2
- 7Bend angle90° ±1°
- 8Material thicknesst 3.0 ±0.1
Stopwatch
0:00.0
BY HAND = 3 TO 4 HOURS OF RETYPING TOLERANCES INTO A PDF TOOL
Notes · what gets ballooned
- 1.Every dimension and tolerance, inch or metric, including limits and basic dimensions.
- 2.GD&T feature control frames and datums.
- 3.Threads, chamfers, radii, hole callouts and counts like 4× or TYP.
- 4.Drawing notes, material callouts and title-block general tolerances.
- 5.Every sheet of a multi-sheet print, from a clean PDF to a forty-year-old scan or a phone photo.
Notes · how it balloons
- 1.Each balloon parks beside its own callout with a leader, clear of geometry and dimension text.
- 2.Numbered in order around the sheet, so your inspector reads the print the way they always have.
- 3.The balloon number becomes the row number in the PFMEA, the control plan and the dimensional layout.
- 4.You get the ballooned drawing back as a PDF, with the characteristics list already in your customer's template.
Every balloon, carried through every document.
The balloon number on the print is the row number in the PFMEA, the control plan and the dimensional layout. Your customer can trace any line back to a feature on the drawing. Tap a balloon.
Balloon 2 · Bearing bore
⌀68.0 H7
RESULT CELLS STAY EMPTY UNTIL YOU UPLOAD MEASUREMENTS. WE NEVER FILL THEM IN.
All 18 elements of a Level 3 PPAP, accounted for.
AIAG PPAP 4th edition. Here is exactly who produces what, so nothing on the submission is a surprise.
- PXL Kraft builds it
- 9
- You supply, we format
- 2
- You supply
- 7
- 01Design record (ballooned drawing)BUILT FROM YOUR PRINTPXL
- 02Engineering change documentsYOU
- 03Customer engineering approvalYOU
- 04Design FMEAYOU
- 05Process flow diagramFROM YOUR ROUTINGPXL
- 06Process FMEADRAFT, YOU SIGN OFFPXL
- 07Control planKEYED TO BALLOONSPXL
- 08MSA studiesYOUR DATA, FORMATTEDYOU + FMT
- 09Dimensional layoutFROM YOUR MEASUREMENTSPXL
- 10Material / performance certsYOUR CERTS, INDEXEDYOU + FMT
- 11Initial process study (Cpk / Ppk)CALCULATED FROM YOUR DATAPXL
- 12Qualified lab documentationYOU
- 13Appearance approval reportYOU
- 14Sample production partsYOU
- 15Master sampleYOU
- 16Checking-aids listPXL
- 17Customer-specific requirementsFORD · GM · STELLANTIS · KOHLER · AIAGPXL
- 18Part Submission Warrant (PSW)FILLED, READY TO SIGNPXL
We compile. You measure.
We never invent a measurement, a Cpk, a cert, or a signature.
Aerospace or medical shop? Same platform, AS9102 Rev C Forms 1–3 in your FAI template.
A Level 3 takes your quality engineer two to three days and shows up a week later. Upload it here and it’s back in minutes.
One Level 3 PPAP · two working weeks
1 COLUMN = 1 DAY
In-house
16–24 H · 1–2 WK
PXL Kraft
BACK IN MINUTES
In-house
16–24 ENGINEER-HOURS- 3–4 hBalloon the drawing by hand, retyping every tolerance.
- 3–4 hDraft the PFMEA from a blank sheet or the last similar job.
- 2–3 hBuild the control plan row by row.
- 2–3 hType the dimensional layout and key in results.
- 3–5 hAssemble the binder, check CSRs, fill the PSW.
1–2 weeks elapsed, because it happens between other jobs
With PXL Kraft
ABOUT 1 HOUR OF YOUR TIME- ~15 minUpload the drawing and your routing.
- SecondsEvery characteristic ballooned. Nothing retyped.
- MinutesThe full package back, engineer-reviewed.
- ~45 minReview it with your team and sign the PSW.
Ballooned in seconds · engineer-reviewed · back in minutes
Your numbers
Recovered per year
7.5
engineer-weeks
300 HOURS · 40 H WEEK · NET OF ~1 H PER PACKAGE ON YOUR SIDE
PXL Kraft drafts engineering judgement. It never invents evidence.
An AI that fabricates a Cpk is worse than no AI at all. So the boundary is architectural, not a policy note: evidence can only enter the system by a person uploading it, and nothing ships until a person releases it.
- Measurement resultsNEVER GENERATED
- Capability indices (Cp / Cpk)NEVER GENERATED
- Laboratory certificatesNEVER GENERATED
- SignaturesNEVER GENERATED
- Customer approvalsNEVER GENERATED
DRAFT BY DEFAULT
Every document stays DRAFT until a named engineer approves it.
COVERAGE GATE
No sheet is approved until balloon coverage passes, or a reviewer records a disposition.
FULL AUDIT TRAIL
Every action, human or machine, timestamped and attributed. Exportable.
- No ITAR or export-controlled work. Every upload carries an attestation.
- Drawings deleted 30 days after the job closes. Never used to train models.
- A named engineer on every released package.
The gap between those two stamps is a human decision.
It always will be.
Run your next PPAP on us.
Pick a real part with a real deadline. If the package isn't something you'd submit, you've lost fifteen minutes.
- 01
Book a 15-minute call
Tell us the part, the customer and the deadline.
- 02
Upload your drawing and routing
Any format, any age. Multi-sheet is fine.
- 03
Get the package back in minutes
Ballooned in seconds, engineer-reviewed, in your customer's template. Judge it yourself.
Pricing is per package or a monthly desk. We price it on the call, after you’ve seen the output.
OR PICK A TIME ON THE TRIAL PAGE →Groups and Tier-1s (multi-site, private deployment): talk to us on the same call
See the output before you send us anything.
Sample Level 3 package: fictional part, real process. Drag the handle to see the raw print become element 1.
- 01Ballooned drawing
- 02Process flow
- 03PFMEA (draft)
- 04Control plan
- 05Dimensional layout
- 06Cpk / Ppk study
- 07Checking-aids list
- 08CSR check
- 09PSW
What quality managers ask us first.
01What do I actually send you?
The customer drawing and the routing you already run. When you have them, your measurement results and material certs. That's it. No CAD model needed.
02How fast is the ballooning?
Seconds. PXL Kraft reads the print and balloons every characteristic, including GD&T, threads, notes and general tolerances, in seconds. The same job by hand is three to four hours of retyping.
03How can the whole package come back in minutes?
Ballooning takes seconds, and every document after it is built from those balloon numbers and your routing, so nothing is retyped. A named engineer checks every characteristic before release, and the package comes back in minutes.
04Our prints are old scans. Will it read them?
Yes. Any age, any format: vector PDF, scanned paper, DXF or a phone photo, single or multi-sheet. Inch or metric, including title-block general tolerances.
05Whose template does the package use?
Your customer's own template. The binder is checked against customer-specific requirements for Ford, GM, Stellantis and Kohler, or generic AIAG when there are none.
06Do you measure parts or make up capability numbers?
Never. You measure; we compile. The dimensional layout and the Cpk / Ppk study are built only from data you upload. We never invent a measurement, a Cpk, a cert or a signature.
07Who checks the AI's work?
A named engineer checks every characteristic before anything is released, and their name is on the package. Every document stays draft until then.
08We also do aerospace and medical work.
Same platform. It produces AS9102 Rev C Forms 1–3 for first article inspection, in your FAI template.
09What happens to our drawings?
Encrypted at rest and isolated per company. Deleted 30 days after the job closes, and never used to train models. We don't accept ITAR or export-controlled work; every upload carries an attestation.
10How is it priced?
Per package, or a monthly desk if you run a lot of them. We price it on the call, after you've seen the output from your free trial PPAP.
The demo policy
Bring your ugliest drawing.
A forty-year-old scan. A phone photo of a fax. A six-sheet pack with hand-written revisions. If PXL Kraft can’t read it, the demo ends early. That’s the deal.
